All variants of this product:
| Item number | Length (mm) | Width (mm) | Height (mm) | Designated purpose | Technical specifications | Weight | variant_1 | variant_2 | variant_3 | variant_4 | variant_5 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 117911R | 1815 | 170 | 70 | Hot-dip galvanized | material: steel surface spindle: galvanized surface tube: coated black Maximum load at 45 degrees: in compression 40-29,2 KN, in tension 40 KN |
19.63 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3556&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 1.80 - 3.20 m Load at 45° in compression: 40,0 - 29,2 kN | without end joints | |||||
| 117931R | 3615 | 170 | 70 | Hot-dip galvanized | material: steel surface spindel: galvanized surface tube: coated black maximum load at 45 degrees: in compression 31,4-10,8 KN, in tension 40 KN |
31.35 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3558&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 3.60 - 5.00 m Load at 45° in compression: 31,4 - 10,8 kN | without end joints | |||||
| 117921R | 2615 | 170 | 70 | Hot-dip galvanized | material: steel surface spindle: galvanized surface tube: coated black maximum load at 45 degrees: in compression 38,8-12,8 KN, in tension 40 KN |
24.84 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3559&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 2.60 - 4.00 m Load at 45° in compression: 38,8 - 12,8 kN | without end joints | |||||
| 117901R | 915 | 170 | 70 | Hot-dip galvanized | Material: steel surface spindel: galvanized surface tube: coated black maximum load at 45 degrees: in compression 40-40KN, in tension 40 KN |
10.27 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3560&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 0.90 - 1.50 mLoad at 45° in compression: 40,0 - 40,0 kN | without end joints | |||||
| 117951R | 6215 | 170 | 70 | Hot-dip galvanized | material: steel surface spindle: galvanized surface tube: coated black maximum load at 45 degrees: in compression 22,9-7,6 KN, in tension 40 KN |
48.27 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3561&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 6.20 - 7.60 m Load at 45° in compression: 22.9 - 7.6 kN | without end joints | |||||
| 117941R | 4815 | 170 | 70 | Hot-dip galvanized | material: steel surface spindle: galvanized surface tube: coated black maximum load at 45 degrees: in compression 26,4-8,9 KN, in tension 40 KN |
39.16 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3562&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 4.80 - 6.20 m Load at 45° in compression: 26,4 - 8,9 kN | without end joints | |||||
| 117911R-EG | 1815 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
23.888 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3564&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 1.80 - 3.20 m Load at 45° in compression: 40,0 - 29,2 kN | with end joints | |||||
| 117901R-EG | 915 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
13.788 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3566&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 0.90 - 1.50 m Load at 45° in compression: 40,0 - 40,0 kN | with end joints | |||||
| 117951R-EG | 6215 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
51.188 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3567&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 6.20 - 7.60 m Load at 45° in compression: 22.9 - 7.6 kN | with end joints | |||||
| 117931R-EG | 3615 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
35.588 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3568&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 3.60 - 5.00 m Load at 45° in compression: 31,4 - 10,8 kN | with end joints | |||||
| 117921R-EG | 2615 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
29.088 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3569&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 2.60 - 4.00 m Load at 45° in compression: 38,8 - 12,8 kN | with end joints | |||||
| 117941R-EG | 4815 | 170 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanizing according to DIN ISO 1461 |
43.388 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3570&variant_2=3565&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 4.80 - 6.20 m Load at 45° in compression: 26,4 - 8,9 kN | with end joints | |||||
| 117901R-OL | 915 | 170 | 70 | Material: steel surface spindel: galvanized surface tube: coated black maximum load at 45 degrees: in compression 40-40KN, in tension 40 KN |
10.27 | https://www.schake.com/en/products/construction-equipment-traffic-safety/formwork/push-pull-strut/v1179r.html?variant_1=3571&variant_2=3557&variant_3=1&variant_4=1&variant_5=1 | Adjustment range: 0.90 - 1.50 mLoad at 45° in compression: 40,0 - 40,0 kN | without end joints |
