All variants of this product:
| Item number | Length (mm) | Width (mm) | Height (mm) | Designated purpose | Technical specifications | Weight | variant_1 | variant_2 | variant_3 | variant_4 | variant_5 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 33620K-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR posts surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
19.944 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3990&variant_2=3991&variant_3=3992&variant_4=1&variant_5=1 | film RA1/A | red / white | without lamp adapter | |||||
| 33620KA2-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR post surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
29.494 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3993&variant_2=3991&variant_3=3994&variant_4=1&variant_5=1 | film RA2/B | red / white | with lamp adapter | |||||
| 33620KA-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR post surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
29.494 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3990&variant_2=3991&variant_3=3994&variant_4=1&variant_5=1 | film RA1/A | red / white | with lamp adapter | |||||
| 33620K2-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR post surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
27.444 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3993&variant_2=3991&variant_3=3992&variant_4=1&variant_5=1 | film RA2/B | red / white | without lamp adapter | |||||
| 33620KSK-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR posts surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
27.544 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3990&variant_2=3995&variant_3=3992&variant_4=1&variant_5=1 | film RA1/A | red / yellow | without lamp adapter | |||||
| 33620K3SK-BF | 2000 | 1000 | 50 | fence material: HDPE plastic, white posts material: structural steel S235 JR post surface: hot-dip galvanized in accordance with DIN ISO 1461 Special note: Can be used with base plates with ø 42.0 mm opening |
27.444 | https://www.schake.com/en/products/construction-equipment-traffic-safety/traffic-safety/panel-fence/v33620k-bf.html?variant_1=3996&variant_2=3995&variant_3=3992&variant_4=1&variant_5=1 | film RA2/C | red / yellow | without lamp adapter |
