All variants of this product:
| Item number | Length (mm) | Width (mm) | Height (mm) | Designated purpose | Technical specifications | Weight | variant_1 | variant_2 | variant_3 | variant_4 | variant_5 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 417_30B | 3000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
38.69 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1635&variant_2=1636&variant_3=1637&variant_4=1&variant_5=1 | fixed, 70 x 70 mm, for casting in concrete | total width: 3000 mm | clear height: approx. 2000 mm | ||||
| 417_32B | 3000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
65.94 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1638&variant_2=1636&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, for casting in concrete | total width: 3000 mm | clear height: approx. 2300 mm | ||||
| 417_40B | 4000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
42.35 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1635&variant_2=1640&variant_3=1637&variant_4=1&variant_5=1 | fixed, 70 x 70 mm, for casting in concrete | total width: 4000 mm | clear height: approx. 2000 mm | ||||
| 417_42B | 4000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
68.33 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1638&variant_2=1640&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, for casting in concrete | total width: 4000 mm | clear height: approx. 2300 mm | ||||
| 417_52B | 5000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
70.71 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1638&variant_2=1641&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, for casting in concrete | total width: 5000 mm | clear height: approx. 2300 mm | ||||
| 417_30BP | 3000 | 2075 | 200 | Hot-dip galvanized | 39.35 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1643&variant_2=1636&variant_3=1637&variant_4=1&variant_5=1 | fixed, 70 x 70 mm, to be fixed by plugs | total width: 3000 mm | clear height: approx. 2000 mm | |||||
| 417_62B | 6000 | 490 | 70 | Hot-dip galvanized | material: S235 JR surface: hot dipped galvanized and powder coated |
73.05 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1638&variant_2=1642&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, for casting in concrete | total width: 6000 mm | clear height: approx. 2300 mm | ||||
| 417_40BP | 4000 | 2075 | 200 | Hot-dip galvanized | 43.01 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1643&variant_2=1640&variant_3=1637&variant_4=1&variant_5=1 | fixed, 70 x 70 mm, to be fixed by plugs | total width: 4000 mm | clear height: approx. 2000 mm | |||||
| 417_32BP | 3000 | 2416 | 100 | Hot-dip galvanized | 69.6 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1644&variant_2=1636&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, to be fixed by plugs | total width: 3000 mm | clear height: approx. 2300 mm | |||||
| 417_42BP | 4000 | 2416 | 100 | Hot-dip galvanized | 71.98 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1644&variant_2=1640&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, to be fixed by plugs | total width: 4000 mm | clear height: approx. 2300 mm | |||||
| 417_52BP | 5000 | 2416 | 100 | Hot-dip galvanized | 74.36 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1644&variant_2=1641&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, to be fixed by plugs | total width: 5000 mm | clear height: approx. 2300 mm | |||||
| 417_62BP | 6000 | 2416 | 100 | Hot-dip galvanized | 76.7 | https://www.schake.com/en/products/urban-equipment/barrier-elements/height-restriction-barriers/v417_30b.html?variant_1=1644&variant_2=1642&variant_3=1639&variant_4=1&variant_5=1 | fixed, 100 x 100 mm, to be fixed by plugs | total width: 6000 mm | clear height: approx. 2300 mm |
