Post configuration - Schake GmbH

Item number	Length (mm)	Width (mm)	Height (mm)	Weight		variant_1	variant_2	variant_3
460B_RAL9005FS_RW1A	1300	60	60	4.91	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460b_ral9005fs_rw1a	Ø 60 mm	stationary	for casting in concrete with ground anchor total length: approx. 1300 mm
460PB_RAL9005FS_RW1A	900	150	100	4	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460pb_ral9005fs_rw1a	Ø 60 mm	stationary	to be fixed by plugs with base plate 100 x 150 mm
476PB_RAL9005FS_RW1A	900	150	100	5.09	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476pb_ral9005fs_rw1a	Ø 76 mm	stationary	to be fixed by plugs with base plate 100 x 150 mm
470PB_RAL9005FS_RW1A	900	150	100	5.55	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470pb_ral9005fs_rw1a	70 x 70 mm	stationary	to be fixed by plugs with base plate 100 x 150 mm
476B_RAL9005FS_RW1A	1400	76	76	6.93	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476b_ral9005fs_rw1a	Ø 76 mm	stationary	for casting in concrete with ground anchor total length: approx. 1300 mm
470B_RAL9005FS_RW1A	1300	70	70	7.12	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470b_ral9005fs_rw1a	70 x 70 mm	stationary	for casting in concrete with ground anchor total length: approx. 1300 mm
460FB_RAL9005FS_RW1A	1300	60	60	6.61	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460fb_ral9005fs_rw1a	Ø 60 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
460ZB_RAL9005FS_RW1A	1300	600	60	7.92	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460zb_ral9005fs_rw1a	Ø 60 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
476ZB_RAL9005FS_RW1A	1300	76	76	11.11	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476zb_ral9005fs_rw1a	Ø 76 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
470ZB_RAL9005FS_RW1A	1400	70	70	13.2	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470zb_ral9005fs_rw1a	70 x 70 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
476FB_RAL9005FS_RW1A	1300	76	76	9.73	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476fb_ral9005fs_rw1a	Ø 76 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
470FB_RAL9005FS_RW1A	1400	70	70	11.27	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470fb_ral9005fs_rw1a	70 x 70 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
460FUB_RAL9005FS_RW1A	916	150	100	5.59	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460fub_ral9005fs_rw1a	Ø 60 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with triangular locking mechanism acc. with DIN 3223
476FUB_RAL9005FS_RW1A	917	150	100	7	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476fub_ral9005fs_rw1a	Ø 76 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with triangular locking mechanism acc. with DIN 3223
470FUB_RAL9005FS_RW1A	900	70	70	7.51	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470fub_ral9005fs_rw1a	70 x 70 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with triangular locking mechanism acc. with DIN 3223
460UZB_RAL9005FS_RW1A	900	150	100	6.77	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460uzb_ral9005fs_rw1a	Ø 60 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with Euro profile cylinder lock and three keys
476UZB_RAL9005FS_RW1A	900	150	100	8.93	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476uzb_ral9005fs_rw1a	Ø 76 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with Euro profile cylinder lock and three keys
470UZB_RAL9005FS_RW1A	900	150	100	9.17	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470uzb_ral9005fs_rw1a	70 x 70 mm	foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm	with Euro profile cylinder lock and three keys
460FUHB_RAL9005FS_RW1A	900	150	100	7.89	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460fuhb_ral9005fs_rw1a	Ø 60 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
476FUHB_RAL9005FS_RW1A	1300	76	76	9.3	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476fuhb_ral9005fs_rw1a	Ø 76 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
470FUHB_RAL9005FS_RW1A	1300	70	70	9.81	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470fuhb_ral9005fs_rw1a	70 x 70 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
470UZHB_RAL9005FS_RW1A	1300	70	70	11.47	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-470uzhb_ral9005fs_rw1a	70 x 70 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
476UZHB_RAL9005FS_RW1A	1300	76	76	10.69	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-476uzhb_ral9005fs_rw1a	Ø 76 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
460UZHB_RAL9005FS_RW1A	900	150	100	9.07	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-460uzhb_ral9005fs_rw1a	Ø 60 mm	foldable, self-engaging lockto be fixed by plugs, incl. base rosette, part-no. 470_60, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
489B_RAL9005FS_RW1A	1300	89	89	8.3	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-489b_ral9005fs_rw1a	Ø 89 mm	stationary	for casting in concrete with ground anchor total length: approx. 1300 mm
491B_RAL9005FS_RW1A	1300	102	102	9.54	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-491b_ral9005fs_rw1a	Ø 102 mm	stationary	for casting in concrete with ground anchor total length: approx. 1300 mm
489PB_RAL9005FS_RW1A	900	150	100	6.35	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-489pb_ral9005fs_rw1a	Ø 89 mm	stationary	to be fixed by plugs with base plate 100 x 150 mm
491PB_RAL9005FS_RW1A	900	200	200	8.99	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-491pb_ral9005fs_rw1a	Ø 102 mm	stationary	to be fixed by plugs with base plate 100 x 150 mm
489FB_RAL9005FS_RW1A	1400	89	89	11.68	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-489fb_ral9005fs_rw1a	Ø 89 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
491FB_RAL9005FS_RW1A	1400	102	102	13.95	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-491fb_ral9005fs_rw1a	Ø 102 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with triangular locking mechanism acc. with DIN 3223
489ZB_RAL9005FS_RW1A	1400	89	89	11.78	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-489zb_ral9005fs_rw1a	Ø 89 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
491ZB_RAL9005FS_RW1A	1400	102	102	12.69	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-491zb_ral9005fs_rw1a	Ø 102 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 400 mm below ground	with Euro profile cylinder lock and three keys
40151B_RAL9005FS_RW1A	1500	152	152	19.6	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-40151b_ral9005fs_rw1a	Ø 152 mm	stationary	for casting in concrete with ground anchor total length: approx. 1500 mm
40153B_RAL9005FS_RW1A	1000	220	220	14.03	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-40153b_ral9005fs_rw1a	Ø 152 mm	stationary	to be fixed by plugs with base plate 220 x 220 mm
40151FB_RAL9005FS_RW1A	1500	152	152	18.85	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-40151fb_ral9005fs_rw1a	Ø 152 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 500 mm below ground	with triangular locking mechanism acc. with DIN 3223
40151ZB_RAL9005FS_RW1A	1500	152	152	17.25	https://www.schake.com/en/products/urban-equipment/barrier-posts/barrier-posts/post-configuration/art-40151zb_ral9005fs_rw1a	Ø 152 mm	removable self-engaging lock, incl. base rosette, with hot-dip galvanized ground sleeve, approx. 500 mm below ground	with Euro profile cylinder lock and three keys
