All variants of this product:
| Item number | Length (mm) | Width (mm) | Height (mm) | Designated purpose | Technical specifications | Weight | variant_1 | variant_2 | variant_3 | variant_4 | variant_5 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 468B | 1400 | 60 | 60 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
4.7 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=164&variant_2=165&variant_3=166&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1400 mm | without lock | without eyelet | ||||
| 468B+1 | 1400 | 60 | 60 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
4.73 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=164&variant_2=165&variant_3=172&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1400 mm | without lock | with 1 eyelet | ||||
| 468B+2 | 1400 | 60 | 60 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
4.76 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=164&variant_2=165&variant_3=173&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1400 mm | without lock | with 2 eyelets | ||||
| 468PB | 950 | 150 | 100 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
4 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=169&variant_2=165&variant_3=166&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | without lock | without eyelet | ||||
| 468PB+1 | 950 | 150 | 100 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
4.03 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=169&variant_2=165&variant_3=172&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | without lock | with 1 eyelet | ||||
| 468PB+2 | 950 | 150 | 100 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
4.06 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=169&variant_2=165&variant_3=173&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | without lock | with 2 eyelets | ||||
| 468FB | 1450 | 60 | 60 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
6.6 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=167&variant_2=168&variant_3=166&variant_4=1&variant_5=1 | removable, self-engaging lockwith hot-dip galvanized ground socket part-no. 460.40approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | without eyelet | ||||
| 468FB+1 | 1450 | 60 | 60 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
6.63 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=167&variant_2=168&variant_3=172&variant_4=1&variant_5=1 | removable, self-engaging lockwith hot-dip galvanized ground socket part-no. 460.40approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | with 1 eyelet | ||||
| 468FB+2 | 1450 | 60 | 60 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
6.66 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=167&variant_2=168&variant_3=173&variant_4=1&variant_5=1 | removable, self-engaging lockwith hot-dip galvanized ground socket part-no. 460.40approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | with 2 eyelets | ||||
| 468FUB | 950 | 150 | 100 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
5.6 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=170&variant_2=168&variant_3=166&variant_4=1&variant_5=1 | foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm | with triangular locking mechanism acc. with DIN 3223 | without eyelet | ||||
| 468FUB+1 | 950 | 150 | 100 | RAL fan | 5.63 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=170&variant_2=168&variant_3=172&variant_4=1&variant_5=1 | foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm | with triangular locking mechanism acc. with DIN 3223 | with 1 eyelet | |||||
| 468FUB+2 | 950 | 150 | 100 | RAL fan | 5.66 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=170&variant_2=168&variant_3=173&variant_4=1&variant_5=1 | foldable, self-engaging lockto be fixed by plugs, with base plate 100 x 150 mm | with triangular locking mechanism acc. with DIN 3223 | with 2 eyelets | |||||
| 468FUHB | 1350 | 60 | 60 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
8.1 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=171&variant_2=168&variant_3=166&variant_4=1&variant_5=1 | foldable, self-engaging lockfor casting in concrete, with hot-dip galvanized groundsocket part-no. 470.60, approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | without eyelet | ||||
| 468FUHB+1 | 1350 | 60 | 60 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
8.1 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=171&variant_2=168&variant_3=172&variant_4=1&variant_5=1 | foldable, self-engaging lockfor casting in concrete, with hot-dip galvanized groundsocket part-no. 470.60, approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | with 1 eyelet | ||||
| 468FUHB+2 | 1350 | 60 | 60 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
8.1 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v468b.html?variant_1=171&variant_2=168&variant_3=173&variant_4=1&variant_5=1 | foldable, self-engaging lockfor casting in concrete, with hot-dip galvanized groundsocket part-no. 470.60, approx. 400 mm below ground | with triangular locking mechanism acc. with DIN 3223 | with 2 eyelets |
