All variants of this product:
| Item number | Length (mm) | Width (mm) | Height (mm) | Designated purpose | Technical specifications | Weight | variant_1 | variant_2 | variant_3 | variant_4 | variant_5 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 487B | 1300 | 89 | 89 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
8.2 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=206&variant_2=207&variant_3=1&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1300 mm | without eyelet | |||||
| 487B+1 | 1345 | 89 | 89 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
8.23 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=206&variant_2=212&variant_3=1&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1300 mm | with 1 eyelet | |||||
| 487B+2 | 1345 | 89 | 89 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
8.26 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=206&variant_2=211&variant_3=1&variant_4=1&variant_5=1 | stationary, for casting in concretewith ground anchor, total length approx. 1300 mm | with 2 eyelets | |||||
| 487FB | 950 | 89 | 89 | RAL fan | material: S235 JR surface: hot dipped galvanized and powder coated |
11.9 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=210&variant_2=207&variant_3=1&variant_4=1&variant_5=1 | removable, with triangular locking mechanismacc. with DIN 3223, self-engaging lockwith hot-dip galvanized ground socket part-no. 470.10 | without eyelet | |||||
| 487FB+1 | 1449 | 89 | 89 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
11.93 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=210&variant_2=212&variant_3=1&variant_4=1&variant_5=1 | removable, with triangular locking mechanismacc. with DIN 3223, self-engaging lockwith hot-dip galvanized ground socket part-no. 470.10 | with 1 eyelet | |||||
| 487FB+2 | 1449 | 89 | 89 | RAL fan | material: S235 JR surface: hot-dip galvanized and coated anthracite grey (RAL 7016) |
11.96 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=210&variant_2=211&variant_3=1&variant_4=1&variant_5=1 | removable, with triangular locking mechanismacc. with DIN 3223, self-engaging lockwith hot-dip galvanized ground socket part-no. 470.10 | with 2 eyelets | |||||
| 487PB | 1300 | 89 | 89 | 15 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=2766&variant_2=207&variant_3=1&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | without eyelet | |||||||
| 487PB+2 | 1300 | 89 | 89 | 21.5 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=2766&variant_2=211&variant_3=1&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | with 2 eyelets | |||||||
| 487PB+1 | 1300 | 89 | 89 | 21.5 | https://www.schake.com/en/products/urban-equipment/ornamental-bollards/hemispherical-head/v487b.html?variant_1=2766&variant_2=212&variant_3=1&variant_4=1&variant_5=1 | stationary, to be fixed by plugswith base plate 100 x 150 mm | with 1 eyelet |
